Page 22
5()(5(1&(7(50,1$/675,376',$*5$0VHFWLRQ
TS1-CTHA,L1,CTH1,CTH3,
Used to properly jumper for input voltages to the control
CTH2,CTH4/L2
transformer. L1 is internally connected to control fuse F1.
For 208/240 VAC operation - jumper CTH1 to CTH3 and CTH2 to
CTH4/L2.
For 480 VAC operation - jumper CTH3 to CTH2 only.
Used also for connections to external SCR or IGNITRON
CONTACTORS. When required connect wire (minimum 18
AWG)L1 to L1 side of external contactor.
TS1-CTH4/L2
L2 is used to provide control power. Connect wire (minimum 18
AWG) from one side of line common to the L2 welding transformer
lead. On controls furnished with integrally installed isolation switch
or circuit breaker, L2 is factory installed.
TS1-H1,TS1-H3,TS1-H2,
Used to properly jumper input voltage to the Sense
TS1-H4/XH1
Transformer.
For 208/240 VAC operation - Jumper H1 to H3 and H2 to H4.
For 480 VAC operation - Jumper H3 to H2 only.
Used also for connections to external SCR or IGNITRON
CONTACTORS. When required connect wire (minimum 18
AWG)H4/XH1 to H1 side of external contactor.
5()(5(1&(+22.83(;7(51$/,*1,752178%(&217$&725
VHHVHFWLRQ76LVPRXQWHGRQ3&%
TS2-L1
Factory connected to the TS1-L1 terminal.
TS2-IG1
Connect to the Ignitor Lead of Ignitron tube #1 (The Anode of
Ignitron Tube #1 is connected to L1).
TS2-IG2
Connect to the Ignitor Lead of Ignitron Tube #2 (The Anode of
Ignitron tube #2 is connected to H1).
TS2-H1
Factory connected to the TS1-H4/XH1 terminal.
5()(5(1&(+22.83(;7(51$/6&5&217$&725
VHHVHFWLRQ-DQG-DUHPRXQWHGRQ3&%
NOTE: Do not overtighten J5 or J6.
J5-C
Connect to the cathode of SCR1.
J5-G
Connect to the gate of SCR1.
J6-C
Connect to the cathode of SCR2.
J6-G
Connect to the gate of SCR2.
