Page 8
6&+('8/(180%(56(/(&7,21: Displayed by (22).
There are two possible ways to select the SCHEDULE to be initiated. Schedules can be
selected internally or externally.
INTERNAL: If EXTENDED FUNCTION, SCHEDULE SELECT [SS] is set to
INTERNAL [00], use Push Button switches (20) and (21) to select the desired
SCHEDULE. Push Button switch (21) increments the 10's digit by one and Push Button
switch (20) increments the 1's digit by one. When the maximum number is reached for
either digit, that digit resets to zero.
EXTERNAL: If EXTENDED FUNCTION, SCHEDULE SELECT [SS] is set to
EXTERNAL [01], use the binary combination of TS1-FS7/SS1, TS1-FS11/SS3, to
select the desired SCHEDULE (See section 5.3 CUSTOMER TERMINAL STRIP
CONNECTIONS and EXTENDED FUNCTIONS section 7.3.
352*5$00,1*3$5$0(7(56(/(&7,21
: Push Button (12), LEDs
(7-11 & 13-18).
Using Push Button switch (12) any function can be selected. Use Push Button to shift the
lighted (active) selection down one LED. If no LED is lit, then EXTENDED FUNCTIONS
have been selected. This is necessary when programming the EXTENDED FUNCTIONS
(See section 7.3 EXTENDED FUNCTIONS). EXTENDED FUNCTIONS can be reached
simply by pressing Push Button (12) until all the LEDs (7-11 & 13-18) are off.
7,0(3$5$0(7(56
(Count Functions).
SQUEEZE
........................ 0 to 99 cycles (Programmed 00 = 0 cycle)
WELD/HEAT
..................... 0 to 99 cycles (Programmed 00 = 0 cycle)
HOLD
........................... 0 to 99 cycles (Programmed 00 = 0 cycles)
OFF
............................. 0 to 99 cycles (Programmed 00 = 0 cycle)
IMPULSES
....................... 1 to 99 cycles (Programmed 00 = 1 cycle)
COOL
............................ 0 to 99 cycles (Programmed 00 = 0 cycles)
SLOPE COUNT
.................... 0 to 99 cycles (Programmed 00 = 0 cycles)
648((=(&2817(7) - The time duration for the electrodes to close on the work and
build up pressure before WELD Count begins.
:(/'+($7&2817(8) - The time duration after SQUEEZE COUNT or closure of a
pressure switch that current will flow through the welding transformer. HEAT count (the
time duration that welding current flows in one impulse) is programmed by WELD Count
in impulse welding.
+2/' &2817(10) - The time duration after WELD Count that the welding electrodes
remain in contact with the work to allow the weld nugget to congeal.
2))&2817(11) - In the Repeat mode, the time duration between HOLD Count and
SQUEEZE Count to allow the work to be repositioned.
&22/&2817(14) - The time duration in multiple impulse welding between successive
HEAT impulses.
NOTE: NO ADJUSTMENT is required for power factor or timing to
change from 60 to 50 Hz operation.
