(0(5*(1&<6723 - This is a terminal strip connection that allows all control functions
to be reset upon opening of the EMERGENCY STOP switch. Control will not be re-initiated
automatically upon release of the switch and must be re-initiated through the normal
initiation circuit. Remove the jumper from TS1-ES1 and TS1-GND and install a normally
closed switch. EMERGENCY STOP switch is not furnished with control.
9$/9(&21752/75$16)250(5 - This transformer provides the necessary voltage
for powering the welding machine solenoid valve(s). Input voltage may be either 240 or 480
VAC (see CUSTOMER WIRING DIAGRAM). Output is 115 VAC (Optional low voltage
transformer for certain operations provides a 24/48 VAC output). 150 VA transformer is
standard in R, T, and NEMA enclosures (250 VA transformer optional). A 50 VA
transformer is provided in the S style cabinet. SEE CAUTION BELOW.
&$87,21
When external valve power is used (24-240 VAC). Valve transformer must
be disconnected at TS3-VL1 and TS3-VL2. Caution must be used to
properly insulate the wires from X1 and X2 leads after removing from TS3.
