2-Firmware
Upgrading the firmware is very easy, you will need a PC running
some sort of terminal program, we recommend Tera Term available
at http://hp.vector.co.jp/authors/VA002416/teraterm.html
You will need to configure the terminal program for:
Speed: 57600 baud
Data: 8 bit
Parity: none
Stop bit: 1
Flow control: none
1. Connect the PC and the DMXStreamer together
2. Scroll to menu option 2-1 Change code and press ENTER.
3. Using the terminal program select the SEND FILE option
4. Select the upgrade ROM file e.g dmxstreamer12.rom
5. Press OK
Uploading will start immediately. Monitor the display on the
DMXStreamer, if any errors occur please restart the process from
point 2.
If the programming is successful the display will show
“Programming done”
It is recommended that you scroll to the checksum menu on the
DMXStreamer and check the checksum of the uploaded file against
the reference number on our website.
DMXStreamer User Manual 26
