2. Three phase
Unscrew the front cover with the complimentary hex screwdriver, then
plug wires on each phase into the corresponding connector of EVB300.
9. Recycling and Disposal
In order to comply with the regulations on recycling management of electrical
and electronic wastes in various countries, electrical equipment’s that have
reached its lifetime must be collected separately to the unit or individual that
has obtained the qualification for disposing discarded electrical and electronic
products. For any equipment that you no longer use, please return it to your
dealer for recycling, or send it to an approved recycling unit in your area for
recycling.
10．Contact
Envertech Corporation Ltd.
Tel: +86 21 6858 0086
Web: www.envertec.com
Email: info@envertec.com
Add: No.138, Xinjunhuan road, Minhang District, Shanghai, China
