Envertech EVT400-R User Manual

4
3.3 Datasheet
Model
EVT400
Input Data（DC）
Recommended Input Power Range (STC)
180W～550W+
Max. DC input (V)
60V
Isc PV (Absolute Max.) (A)
25 A
Operating Range (V)
16V-60V
Max. Input Current (A)
14A
Mppt Voltage Range (V)
22V-50V
Output Data（AC）
Nominal Voltage (Vac)
220V/230V
Voltage Range (Vac)
189V-260v
Current (Max. continuous) (A)
1.81A
Frequency (Hz)
50Hz/60Hz
Frequency Range (Hz)
47.5-52.5Hz/57.5-62.5Hz
Power (Max. continuous) (W)
400W
Power Factor /Rated(default)
+/-0.90
Total Harmonic Distortion
<3%
Maximum Units Per Branch(12AWG
Cable)
13 Units
Efficiency
Peak Efficiency
96.5%
MPPT Efficiency
99.9%
Nighttime Power Consumption
<100mW
Features
Communication
PLCC (Power Line Carrier
Communication) / Wi-Fi
Compliance
VDE-AR-N 4105, IEC/EN61000,
IEC/EN62109-1/2, EN50549-
1/2019, TOR 2019, C10/11:2019,
CEI 0-21, UTE C15-712-1:2013,
VFR 2019 ( See individual
datasheet for specific product
certifications )
Warranty
15 Years (20 years optional)
Others
Ingress Protection (IP)
IP 67
Protective Class
Class I
Temperature(℃)
-40℃ to +65℃
Relative Humidity
0%～98%
Overvoltage Category
OVC III (AC Main), OVC II (PV)
Inverter Isolation
☒High Frequency Isolated
Weight
2.1kg
Dimensions (W*H*D)
163.3mm*163.7mm*35.5mm
4. Preparation
4.1 Packing Checklist
After you receive the Envertech microinverter, please check if there is any
damage on the carton, and then check the inside completeness for any visible
external damage on the microinverter and accessories. Contact your dealer if
anything is damaged or missing.
