The Horizontal Vent Kit (50-3664, ICC #TM-ALH) must be used in conjunction with the Q1 Co-linear
Vent Kit (50-2982) and ensure that the unit air restrictors are set to fully open as this venting kit func-
tions best without any restriction. See owner’s manual for more information. See Owner’s Manual for
installation.
This kit is NOT compatible with the Q1 replace conguration.
The kit is directly compatible with the E series units listed below.
Compatible Models:
Q1 General InformatIon
Initial Installation
Step 1:
Remove the Horizontal Vent Kit from the packaging. Ensure there is no damage to the vent piping or
termination cap. If there is damage contact your dealer, distributor, or courier company before start-
ing this installation.
InstallatIon:
Note: Space must be left for the gas line on left side (Q1/E30/EX32) or right side (E33/EX35) of
the unit for servicing purposes
Install Information:
The ue damper must be fully blocked open or removed for installation of the unit; the smoke
shelves, shields and bafes may be removed if attached by mechanical fasteners.
The replace and replace chimney must be clean, in good working order and constructed of non-
combustible materials.
Make sure that all chimney cleanouts are tight tting and will not permit air to leak into the chimney.
Refractory, glass doors, screen rails, screen mesh and log grates can be removed from the replace
before installing the unit.
Install a sealed vent cap to prevent leakage of room air up through chimney.
The intake and the exhaust are 3” (76mm).
Ensure that the replace and chimney have been thoroughly cleaned prior to install.
Horizontal Co-Linear Vent Kit Installation
QUALIFIED INSTALLERS ONLY
• Q1C
• Q1CI
• Q1L
• Q1LI
• Q1G
• Q1GI
• E30
• E30I
• E30G
• E30GI
• E33
• E33I
• E33G
• E33GI
• EX32
• EX35
all Inserts General InformatIon
Step 2:
Determine the best location on the exterior wall of the chimney for the vent terminal. Use Figure 3
and Table 1 as reference for the minimum vertical venting run required.
Note: A taller vent run will allow for a cleaner burning ame.
