Enviro Q1C Manual

*Min. 3’
**Max. 7’
*Minimum vertical height is measured
from the top of the unit to the intake
collar center line
** Maximum vertical height is measured
from the top of the unit to the exhaust
collar center line.
Step 10:
Proceed with regular installation for the
given model as shown in the owner’s
manual.
Note: The intake
collar is closer to
the rear of the
replace for the
Q1.
Initial Installation
QUALIFIED INSTALLERS ONLY
Figure 3: Venting Minimum and Maximum
Fireplace Model Minimum Vent Maximum Vent
Q1G / Q1GI / Q1L / Q1LI 3’ [0.9m] 5’ [1.5m]
Q1C / Q1CI 5’ [1.5m] 7’ [2.1m]
E30 / E30I / E30G / E30GI
6’ [1.8m] 7’ [2.1m]
E33 / E33I / E33G / E33GI
EX32
EX35
Table 1: Required Vent Lengths

Enviro Q1C Specifications

General

Brand	Enviro
Model	Q1C
Category	Indoor Fireplace
Language	English
