Enviro WINDSOR Technical Manual

25
Reference
Number
Description
Part
Number
1 120 °F (49 °C) Ceramic Fan Temperature Sensor EC-001
2 Auger Motor - 220V EF-001-220V
3 Fan Temp Sensor 160 °F (71 °C) EF-013
4 High Limit Temp Sensor 200 °F (93 °C) Manual Reset EF-016
5 Vacuum Switch - 220V EF-017-220V
Silicone Hose EF-018
Aluminum Hose Barb EF-019
6 Ignition Burn Pot EF-021
CE Power Cord - 220V EF-054-220V
External Exhaust Back EF5-143
External Exhaust Box EF5-144
External Exhaust Bottom EF5-145
45° Exhaust Adaptor EF5-146
60° Exterior Exhaust Adaptor 50-096
Door Screen 50-177
7 Slider Damper with bolt 50-180
8 Heat Exchanger Rod 50-181
9 Cast Brick Panel - Center 50-182
10 Cast Brick Panel - Left 50-183
11 Cast Brick Panel - Right 50-184
12 Brick Panel Retainers (set of 2) 50-185
13 Inner Door Complete with Glass & Tape 50-186
14 Glass With Tape 50-187
Inner Door Only - Painted 50-188
15 Inner Door Handle 50-189
16 Door Hinge Bracket 50-190
17 Ash Pan With Painted Knob 50-191
18 Hopper Lid 50-193
19 Back grill 50-194
20 Access Panel - Left 50-195
21 Access Panel - Right 50-196
Parts List - Components

Enviro WINDSOR Specifications

General

Hopper Capacity	60 lbs
Ignition	Automatic
Thermostat	Yes
Fuel Type	Pellet
Venting	3" or 4"
