7
MAINTENANCE
3. Push the impeller clips together with forenger
and thumb and pull impeller towards you.
(Fig.3)
4. Wash the cover and impeller in warm, soapy
water. Dry and replace, as above in reverse.
(Fig.4)
N.B. Use a damp, soapy cloth to clean scroll (NO SOLVENTS)
Fig.3 Fig.4
IQ CONTROL (OPTIONAL)
Remote Control Boost Switch
The Cyclone 7 operates continuously at a low rate
known as ‘trickle’, to ensure that your kitchen or
bathroom is ventilated at the appropriate level.
The Cyclone 7 will automatically vary its extract rate
when it senses an increase in the moisture level
running through the fan. By pressing the button
once on the remote control boost switch, the green
LED will illuminate and the unit will go into boost
mode. The boost time is set to 3.5 minutes.
