SHOULD YOU ENCOUNTER ANY PROBLEMS INSTALLING THIS UNIT CALL
13
The energiSava 300 & 400 are also available as a Plus version. This version is equipped with
a dierent control board with 2 additional connectors (X14 & X15) with more connection
options for various applications.
The 9-pole connector X15 is accessible at the rear of the unit display cover without having
to open the appliance.
The 2-pole connector X14 is accessible after taking o the display cover. The display cover of
the “Plus” version has a second gland. That makes it possible to feed a 230 volt cable, which
may be connected to connector X14, to outside the appliance.
See page 33 for more information on the connection possibilities of connectors X14 and X15.
Plus version
02 Technical Specications
