ENVO D35 | ST EBIKE MANUAL | VERSION 1.0 9
Figure 2C
Figure 2D
Figure 2E
Figure 2F
2.6. BATTERY REMOVAL & INSTALLATION
BATTERY REMOVAL
• Turn the key counterclockwiseto unlock the battery gently
• The lock is located on the left side of the bike Figure 2C
• Hold the battery and push with your thumb while pulling with
your ngers. The battery should easily come off Figure 2D
BATTERY INSTALLATION
• To reinstall, rst gently turn the key into the lock position
• Then line the pins at the back of the battery with the slots
and make sure the battery is aligned Figure 2E
• Give a gentle push towards the back, then rmly press the
front of the battery down. If done correctly, you should hear a
click locking battery into the place
• Make sure the battery is rmly locked before operating the
ebike Figure 2F
