Eonon E0821 - Specifications; Media Playback Specifications; Tuner Specifications

CONTENTS
Precautions 2
Panel illustration
Main menu 5
Media player
AV IN 8
Setup 9
iPod player
Radio operation
TV operation
Location of the Remote Control 14
Remote Control Operation 15
Installation 24
Simple Troubleshooting Guide
Wiring Diagram
Specification 28
28
1
SPECIFICATION
Disc Played DVD/VCD/2.0/MP3/MP4(DIVX/CD/Picture-CD)
Video System PAL/AUTO/NTSC
Video System 4:3Letter Box and 4:3Pan Scan ,16:9wide-screen
Video Output level 1.0vp-p 75ohm
Horizontal Resolution 500
Maximum Output level 2Vrms(+/-3dB)
Frequency Response 20 to 20KHz
Signal-to-noise Ratio 85dB
Separation 80dB
Frequency Range 522-1620(Europe/China/Russia)
530-1710(U.S.A);522-1629(Japan)
IF Range 450KHz
Usable Sensitivity(-20dB) 25dB
Tuning Range 87.5-108(Europe/China);87.5-107.9(U.S.A)
76-90(Japan);65-108(Russia)
IF Range 10.7MHz
Usable Sensitivity 15dB
Signal-to-noise Ratio 60dB
Stereo Separation 30dB(1KHz)
Frequency Response 30-15KHz
General
DVD Deck Section
Video Section
Audio Section
AM Tuner Section
FM Tuner Section
Note: Due to continuous product improvement, specifications and design are
Subject to change, without notice.
Power Requirement 14.4DC
Load Impedance 4ohm
Max Power Output 60W 4
Tone Control +/-8DdB(Bass100Hz,Treble 10KHz)
Dimension Approx,192 188 80mm(D W H)
Mounting Dimension Approx,169 178 50mm(D W H)
Weight Approx.1.75kg
03.MAL.5700.001.27
3
6
10
11
13
26
27
