25
Automatic
This communication mode is compatible with the basic work modes Weight-
Tare, Levels and Part Counting.
After selecting this option, the automatic transmission protocol type is
chosen. The possible values are: 'Await request' or 'Manual'. The scale
automatically sends the weight depending on the trace selected:
Await request trace: <PPP.PPP><CR>
<PPP.PPP> - Value of the weight with 7 bytes including the decimal
point and justified with zeros (0x30) on the left. If the
negative net weight, a string composed of 7 characters
'A' (0x41, 65d) is sent.
<CR> - Character 0x0d.
Manual transmission trace: <STX><ST><PPP.PPP><CR>
<STX> Character 0x02, 2d.
<ST>
Tare status. The possible values are: 'blank' (0x20, 32d)
if the weight is gross, 'T' (0x54, 84d) there is a tare, and
'F' (0x46, 70d) if there is a fixed tare.
<PPP.PPP> - Value of the weight with 7 bytes including the decimal
point and justified with (0x30) on the left. If the weight is
High, Low or negativ, it sends: <AAAAAAA>.
<CR> - Character 0x0d, 13d.
Manual
This communication mode is compatible with the basic work mode Weight-
Tare.
When the key is pressed, if the weight is stable, the scale sends the
weight with the corresponding trace. If the weight is not stable, the scale starts a
stable weight capture sequence. When the weight becomes stable, the scale sends
the weight. If the weight does not stabilize in a preset time (TIME LIMIT), the
weight is not sent and the scale displays an unstable weight error (Error 14).
The trace used in this format is that described in the Automatic transmission
format with Manual transmission trace.
