Coding of the status bytes:
Bit First status byte Second status byte
0 1 – Scale in movement 1 – Weight under
0 – Weight stable 0 – No Weight under
1 1 – Scale at zero 1 – Weight over
0 – Weight <> zero 0 – No Weight over
2 1 – Ram Error 1 – Rom Error
0 – No Ram error 0 – No Rom error
3 1 – Eeprom Error 1 – Calibration failure
0 – No Eeprom error 0 – Calibration OK
4 Always 1 Always 1
5 Always 1 Always 1
6 Always 0 1 – There is a third status byte
0 – Last byte
7 Always 0 Always 0
TPV 8 (DICENTRO Protocol):
TPV Scale
W
Weight:
<STX><PPPPP><CR>
Error:
<STX><'?'><STATUS><CR>
