 Mounting on the wall
Step1: Locate and drill screw holes based
on the frame mounting dimension of the
base, and install the plastic expansion bolts.
Step 2: Fix the frame with four ST4.2×3
self-tapping cross recessed pan head
screws.
Step 3: Use four M4×8 pan head screws
to mount the MT52 panel on the frame.
Step 4: Mount the four associated screw
plugs into the screw holes.
