Mounting on the panel surface
Step 1: Locate and drill screw holes based on the installation size of the surface.
Step 2: Use four M4×8 cross recessed pan head screws with M4 nuts to mount MT52
panel onto the surface.
Step 3: Mount the four associated white screw plugs into the screw holes.
Note: Take full consideration of the plugging/unplugging space and the length of
the communication cable during installation.
