RFRP-OT Room Thermostat CombiPack4
1) The mounting height should be 1.5 metres above the oor level.
2) The thermostat should be wall mounted in the room where the
heating is to be controlled.
The place of installation should be chosen so that the sensor can
measure the room temperature as accurately as possible.
Choose the mounting location to prevent direct exposure to
sunlight or other heating / cooling sources when mounted.
3) Fix the mounting plate directly to the wall with the screws provided.
4) Attach the thermostat to the mounting plate.
5) Lower the ap at the front of the thermostat. There is a battery
compartment located below the buttons. Apply downward
pressure to remove the cover.
6) Insert the 2 x AA batteries and the thermostat will turn on.
Close the battery compartment.
Mounting & Installation (Continued)
