RF1A-OT Wireless Receiver CombiPack4
1) The RF1A-OT receiver should be wall mounted in an area within
20 metres distance of the wireless thermostat. It is important
that the receiver is mounted more than 1 metre away from metal
objects as this will aect communication with the thermostat.
The receiver should be installed at least 1metre from any electronic
devices such as radio, TV, microwave or wireless network adaptor.
2) Slacken the fastening screw on the bottom of the receiver with a
philips screwdriver. The receiver is hinged and can be opened 180
degrees.
3) Screw the receiver to the wall with the screws provided.
4) Remove the protective cover on the terminal block.
5) Insert wires into therminal block in accordance with the wiring
diagram.
6) Close the cover and tighten the fastening screw.
Mounting & Installation
