17000 X-Axis Assembly Replacement
Fusion Edge & Fusion Pro X-Axis Assembly Reference Guide
Model Part Number Description
Maker 12 LC1060-TS Assy, X-Axis Rail, 24x12, Maker, TS
Edge 12 CO2 LC0485-TS Assy, X-Axis Rail, 24x12, CO2, TS
Edge 12 Fiber LC0486-TS Assy, X-Axis Rail, 24x12, Fiber, TS
Edge 24 CO2 LC0970-TS Assy, X-Axis Rail, 24x24, Edge, CO2, TS
Edge 24 Fiber LC0971-TS Assy, X-Axis Rail, 24x24, Pro, Fiber, TS
Pro 24 CO2 LC1034-TS Assy, X-Axis Rail, 24x24, Pro, CO2, TS
Pro 24 Dual LC1035-TS Assy, X-Axis Rail, 24x24, Pro, Dual, TS
Edge 36 CO2 LC1056-TS Assy, X-Axis Rail, 36x24, Edge, CO2, TS
Pro 36 CO2 LC1057-TS Assy, X-Axis Rail, 36x24, Pro, CO2, TS
Pro 36 Dual LC1058-TS Assy, X-Axis Rail, 36x24, Pro, Dual, TS
2
Fusion Maker engravers are not manufactured with the x-axis drive board
referenced in this document. If removing the x-axis assembly in a Fusion Maker,
disregard steps which reference the x-axis drive board.
