Epilog Laser Fusion User Manual

Adjusting the Table Level
Fusion and FiberMark Fusion
Revision Date: 9/10/2014 pg. 10 of 10
Step 6: Lock the Adjustment Wheel
Tighten the two 3/32” Allen screws on the bottom of the Table Level Adjuster.
This will lock the level in place
Step 7: Replace Exhaust Weldment

Epilog Laser Fusion Specifications

General

Laser Type	CO2
Max Material Thickness	12.25" (311 mm)
Resolution	Up to 1200 DPI
Connectivity	Ethernet, USB
Operating Modes	Raster, Vector or Combined
Interface	Touchscreen control panel
Power Supply	110V or 220V, depending on model
Cooling	Water-cooled laser tubes
Software	Epilog Laser Dashboard
Supported File Formats	AI, BMP, DXF, EPS, GIF, JPG, PDF, PLT, PNG
Warranty	1 year limited warranty
Z Table Travel	Varies by model (typically 12 in)
Exhaust	Required, external blower recommended

Summary

Adjusting the Table Level

Procedure A: Check Table Level

Guides through checking the table level using the manual focus gauge.

Determining Which Corners Need to Be Leveled

Identifies which corners require adjustment based on the reference corner.

Procedure B: Adjusting the Front Corners

Details the steps for adjusting the front corners of the table level.

Procedure C: Adjusting the Rear Corners

Details the steps for adjusting the rear corners of the table level.
