Installation
Page 3-6
NOTES:
DIMM#2 & #3 shared same memory bus and DIMM#1 is dedicated for 2
nd
channel memory bus.
Using non-compliant memory with higher bus speeds (overclocking) may
severely compromise the integrity of the system.
<Figure 6>
<Table 1>
DDR DIMM 2
DDR DIMM 1
DDR DIMM 3
Bank 0
Bank 1
3-3 System Memory Configuration
Memory Layout
The mainboard accommodates three PC1600/2100/2700/3200 184-pin DIMMs (Dual In-
line Memory Modules):
Supports up to 3.0GB of 200/266/333/400MHz DDR SDRAM
Supports up to 3 DDR DIMMs (refer to Table 1)
Supports 64/128/256/512Mb, 1Gb x8 & x16 DRAMs
Supports unbuffered and non-ECC DIMMs
Supports configurations defined in the JEDEC DDR DIMM specification
Figure 6 and Table 1 show several possible memory configurations.
MMID1sMMID2sMMID3
1#MMIDSD/SSSD/SSSD/SSSD/SS
2#MMIDSD/SSSD/SSSD/SS
3#MMIDSD/SSSD/SSSD/SS
* SS: Single-Sided DIMM, DS: Double-Sided DIMM
