3.5 LED Indicators
Below Figure 3-6 displays the six LED indicators on the indicating panel of
NAVY Battery: one running indicator, one alarm indicator and four battery
level indicators.
Running
Indicator
Alarm
Indicator
Battery Level
Indicators
Figure 3-6
Battery
Condition
Description Run Alarm
Battery Level
(L-H)
Power off All lights are off
Standby
Normal: indicating power-
saving status
●
Alarm: low-battery

