Epsolar LS1024B - Technical Specifications

9
the environment temperature, the
power of solar module or the
power of the load.
All the led
indicator flashing
(battery red
indicator
flashing)
System voltage
error
Check whether the battery
voltage match with the controller
working voltage. Please change
to a suitable battery or reset the
working voltage. If there is no
abnormal, please press load
button to clear the malfunction.
SOC value
incorrect
Choose the
wrong battery
type; Using the
reconfigured
profile of the
user defined
battery type.
Correct the right battery type;
Using the configuration of the
charging voltage compensation if
choosing the user defined battery
type and ignore the SOC
6Technical specifications
Electrical Parameters
Description Parameter
Nominal System Voltage 12 /24VDC
Max. PV input voltage 50V
Max. Battery Terminal Voltage 34V
Rated Battery Current
LS1024B 10A
LS2024B 20A
LS3024B 30A
Charge Circuit Voltage Drop ≤0.28V
Discharge Circuit Voltage Drop ≤0.20V
Self-consumption
≤8.4mA/12V;
≤7. 8mA/24V
Temperature compensation coefficient -3mV//2V (Default)
Grounding Positive grounding
