Epson CW-C6500Ae User Manual

User’s Guide
M00123500EN
Before use
Basic Operation
Maintenance
Troubleshooting
Specifications
Appendix

Epson CW-C6500Ae Specifications

General

Maximum Print Resolution	1200 x 1200 dpi
Auto Cutter	Yes
Print Resolution	1200 x 1200 dpi
Duplex Printing	No
Media Type	Fanfold
Media Thickness	0.07 - 0.8 mm
Roll Outer Diameter	150 mm (6 inches)
Roll Core Diameter	3 inches
Interfaces	USB 2.0, Ethernet
Operating Systems	Windows, Mac OS
Printer Language	ESC/Label
Ink Type	Pigment ink
Connectivity	USB, Ethernet
Ink Cartridge Configuration	4 individual ink cartridges (Cyan, Magenta, Yellow, Black)
Operating System Compatibility	Windows
