Epson DS-1630 User Manual

46
You see a window like this:
Note: If you want to use a scan job that you created instead, select it from the Job list in the
Document Capture window, click the Start Job button, and skip the rest of these steps.
4. Select any displayed scan settings you want to use.
Note: See the Help information in Document Capture for details.
5. If you want to select detailed scan settings, close the Scan Settings window, open the Scan menu at
the top of the Mac desktop, and select Displays the EPSON Scan Setup Screen.
6. Click the Scan icon and select any detailed scan settings you want to use from the Epson Scan 2
window.
7. Click Scan.

Epson DS-1630 Specifications

General

Display	LCD
Scanner type	Flatbed scanner
Product color	Black, White
Built-in display	No
Film scanning	-
Color scanning	Yes
Maximum scan size	210 x 3048 mm
ADF scan speed (b/w, A4)	25 ppm
Enhanced scan resolution	1200 x 1200 DPI
Optical scanning resolution	600 x 600 DPI
Maximum scan area (ADF)	89 x 127 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Scan drivers	ISIS, TWAIN
Scan file formats	PDF, TIFF
Scanning noise level	55 dB
Daily duty cycle (max)	1500 pages
Auto document feeder (ADF) input capacity	50 sheets
USB version	3.2 Gen 1 (3.1 Gen 1)
Standard interfaces	USB 3.2 Gen 1 (3.1 Gen 1)
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, USB
Power supply type	AC
Supported network protocols	TCP/IP, DHCP, DNS, SNMP, SLP
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	315 mm
Width	451 mm
Height	120 mm
Weight	3700 g
