Epson DS-5500 - Page 11

To Next Page

To Previous Page

a Automatic Document Feeder (ADF)

b ADF cover

c Edge guides

d ADF input tray

e ADF output tray

f Control panel

a Document cover

b Document glass

c Carriage (in the document glass)
