Supported Monitor Display Resolutions
192
The tables here list the compatible refresh rate and resolution for each
compatible video display format.
Computer Signals (Analog RGB)
Signal Refresh rate (Hz) Resolution (dots)
VGA 60/72/75/85 640 × 480
SVGA 60/72/75/85 800 × 600
XGA 60/70/75/85 1024 × 768
WXGA 60 1280 × 768
60 1366 × 768
60/75/85 1280 × 800
WXGA+ 60/75/85 1440 × 900
WXGA++ 60 1600 × 900
SXGA 70/75/85 1152 × 864
60/75/85 1280 × 960
60/75/85 1280 × 1024
SXGA+ 60/75 1400 × 1050
WSXGA+ * 60 1680 × 1050
UXGA 60 1600 × 1200
1920 × 1080 ** 50/60 1920 × 1080
* Available only for projectors with a resolution of Full HD (1,920 × 1,080) or
WXGA (1,280 × 800), and compatible only when Wide is selected as the
Resolution setting in the projector's Signal menu.
** Available only for projectors with a resolution of Full HD (1,920 × 1,080).
Even when signals other than those mentioned above are input, it is likely that
the image can be projected. However, not all functions may be supported.
Composite Video
Signal Refresh rate (Hz) Resolution (dots)
TV (NTSC) 60 720 × 480
TV (SECAM) 50 720 × 576
TV (PAL) 50/60 720 × 576
HDMI Port Input Signals
Signal Refresh rate (Hz) Resolution (dots)
VGA 60 640 × 480
SVGA 60 800 × 600
XGA 60 1024 × 768
WXGA 60 1280 × 800
60 1366 × 768
WXGA+ 60 1440 × 900
WXGA++ 60 1600 × 900
SXGA 60 1280 × 960
60 1280 × 1024
SXGA+ 60 1400 × 1050
WSXGA+ * 60 1680 × 1050
UXGA 60 1600 × 1200
1920 × 1080 50/60 1920 × 1080
WUXGA (Reduced
Blanking) **
60 1920 × 1200
SDTV (480i/480p) 59.94 720 × 480
SDTV (576i/576p) 50 720 × 576
HDTV (720p) 50/59.94/60 1280 × 720
HDTV (1080i) 50/59.94/60 1920 × 1080
HDTV (1080p) 23.98/24/29.97/30/50/59.94/60 1920 × 1080
