Epson EB-1485Fi Installation Guide

Contents
3
Adjusting the Interactive Pen
Calibrating the Interactive Pen ........ 86
Manual Calibration ...................... 86
Auto Calibration.......................88
Installing the Touch Unit
Notes on handling the Touch Unit . . . . . 90
For Canadian Users .....................91
Touch Unit installation location ....... 92
Notes on the Touch Unit Bracket ............ 93
Notes on the Laser ................... 94
Attached labels ........................ 94
Laser diffusion port ..................... 94
Touch Unit Specifications ............. 96
External dimensions ..................... 96
Touch Unit Bracket Specifications ..... 97
External dimensions ..................... 97
Adjustment range ...................... 98
Installing the Touch Unit ............. 99
Installing the infrared deflectors ............99
Installing the Touch Unit ................. 100
When installing on the projection surface
without using the Touch Unit Bracket..... 100
When using the Touch Unit Bracket to install
outside of the projection surface .........103
Attaching a Security Cable ............... 108
Turning on the Touch Unit ............... 109
Adjusting the Angle of the Laser (Touch Unit
Auto Setup) .......................... 110
When auto adjustment fails............ 116
Calibrating the touch operation position ..... 119
Setting the Projector
Batch Setup Function ............... 122
Setup Using a USB flash drive ............. 122
Saving settings to the USB flash drive..... 122
Copying saved settings to other projectors . 123
Setup by Connecting the Computer and
Projector with a USB Cable ............... 124
Saving settings to a computer ........... 124
Copying saved settings to other projectors . 125
When Setup Fails ...................... 127
Installing Multiple Projectors (Multi-
Projection) ......................... 128
Setting the Projector ID ................. 128
Multi-Projection Connection Settings . . . . . . . 130
When using the interactive functions . . . . . . 130
When not using the interactive functions . . . 132
HDMI Link settings ..................... 133
Adjusting the Image in Multi-Projection ......134
Projector Sync. Settings (only when using
interactive functions) ................... 135
EDID settings (only when using interactive
functions) ........................... 136
Appendix
List of Safety Symbols ............... 138
General Notice ..................... 141

Epson EB-1485Fi Specifications

General

Matrix size	0.62 \
Heat dissipation	1244 BTU/h
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	0 - 0.78 m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 100 \
Projection distance (tele)	0 - 0.6 m
Projection distance (wide)	0 - 0.4 m
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	3500 ANSI lumens
Focus	Manual
Throw ratio	0.27 - 0.37:1
Zoom capability	Yes
Fixed focal length	3.9 mm
Power source	AC
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	366 W
Power consumption (economy mode)	262 W
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
DVI port	No
Composite video in	0
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Component video (YPbPr/YCbCr) in	1
Mobile High-Definition Link (MHL)	-
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	36 dB
Country of origin	China
Interactive input supported	Interactive pen/Touch
Noise level (economic mode)	27 dB
Compatible operating systems	Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Windows 10, Windows 10 (32/64 bit), Windows 2000
Placement	Wall
Product type	Ultra short throw projector
Product color	White
Market positioning	Business
Cable lock slot type	Kensington
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode
Supported video modes	1080p
Supported graphics resolutions	1920 x 1080 (HD 1080)
RMS rated power	16 W
Storage temperature (T-T)	-10 - 60 °C
Bundled software	Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projektor Management
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	6 pc(s)
Quantity per pallet (UK)	12 pc(s)
Harmonized System (HS) code	85286200
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Sustainability certificates	TCO
Software support	via: AMX, Crestron (Network), Extron, Crestron (RS-232C only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol
Windows operating systems supported	Windows 10, Windows 10 x64, Windows 2000

Weight and Dimensions

Depth	375 mm
Width	458 mm
Height	210 mm
Weight	9300 g
Package depth	590 mm
Package width	472 mm
Package height	640 mm
Package weight	27700 g
