d

Install the new air filter.

Slide the air filter from the outside and press in until it firmly clicks

into place.

e

Close the air filter cover.

a

Dispose of used air filters properly in accordance with your

local regulations.

Filter frame: ABS

Filter: Polyurethane foam

Replacing Consumables

125
