Connecting a LAN Cable

Only EB-X25/EB-W22/EB-X22/EB-X20 are supported.

Connect a LAN port on network hubs or other equipment to the projector's LAN port with a commercially available 100BASE-TX or 10BASE-T LAN

cable.

By connecting a computer to the projector over a network, you can project images and check the status of the projector.

To prevent malfunctions, use a category 5 or higher shielded LAN cable.
