To Next Page

To Previous Page

4:3 Screen Size

Minimum (Wide) to

Maximum (Tele)

Wide

70" 142x107 207 - 280 -12

80" 160x120 237 - 321 -13

100" 200x150 297 - 401 -17

150" 300x230 446 - 603 -25

200" 410x300 595 - 805 -33

Unit: cm

16:9 Screen Size

Minimum (Wide) to

Maximum (Tele)

Wide

28" 62x35 89 - 121 1

30" 66x37 96 - 130 1

50" 110x62 161 - 218 1

60" 130x75 193 - 262 2

70" 155x87 226 - 306 2

80" 180x100 258 - 349 2

100" 220x120 323 - 437 3

150" 330x190 486 - 657 4

200" 440x250 649 - 877 5

Screen Size and Projection Distance

132

Notations Used in this Guide2
- Table of Contents3
Introduction7
Projector Features8
- Quick and Easy Set Up, Projection, and Storage8
- Useful Functions for Projecting Images8
- Taking Full Advantage of a Network Connection9
Part Names and Functions11
- Front/Top11
- Rear13
- Base14
- Control Panel15
- Remote Control16
  - Replacing the Remote Control Batteries19
  - Remote Control Operating Range20
Preparing the Projector21
Installing the Projector22
- Installation Methods22
  - Installation Methods23
- Screen Size and Approximate Projection Distance23
Connecting Equipment25
- Connecting a Computer25
- Connecting Image Sources26
- Connecting USB Devices27
- Connecting External Equipment28
- Connecting a LAN Cable30
- Installing the Wireless LAN Unit31
  - Installing the Quick Wireless Connection USB Key32
Basic Usage33
Projecting Images34
- From Installation to Projection34
- Automatically Detect Input Signals and Change the Projected Image (Source Search)35
- Switching to the Target Image by Remote Control36
- Projecting with USB Display36
Adjusting Projected Images40
- Correcting Keystone Distortion40
  - Correcting Automatically41
  - Correcting Manually41
- Adjusting the Image Size44
- Adjusting the Image Position45
- Adjusting the Horizontal Tilt45
- Correcting the Focus45
Contents46
- Adjusting the Volume46
- Selecting the Projection Quality (Selecting Color Mode)46
- Setting Auto Iris47
- Changing the Aspect Ratio of the Projected Image47
  - Changing Methods48
  - Changing the Aspect Mode48
Useful Functions51
Projection Functions52
- Projecting Without a Computer (PC Free)52
- Hiding the Image and Sound Temporarily (A/V Mute)57
- Freezing the Image (Freeze)58
- Pointer Function (Pointer)58
- Enlarging Part of the Image (E-Zoom)59
- Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse)60
- Saving a User's Logo61
- Saving User Pattern63
Security Functions65
- Managing Users (Password Protect)65
- Restricting Operation (Control Panel Lock)67
- Anti-Theft Lock69
  - Installing the Wire Lock69
Monitoring and Controlling70
- Easymp Monitor70
- Changing Settings Using a Web Browser (Web Control)70
- Using the Mail Notification Function to Report Problems72
  - Reading Error Notification Mail72
- Management Using SNMP73
- ESC/VP21 Commands73
  - Command List73
  - Cable Layouts74
- About Pjlink (EB-X25/EB-W22/EB-X22/EB-X20 Only)75
- About Crestron Roomview ® (EB-X25/EB-W22/EB-X22/EB-X20 Only)75
  - Operating a Projector from Your Computer76
About Event ID80
Configuration Menu81
Using the Configuration Menu82
List of Functions83
- Configuration Menu Table83
  - Network Menu84
- Image Menu85
- Signal Menu86
- Settings Menu88
- Extended Menu89
- Network Menu91
- ECO Menu99
- Info Menu (Display Only)100
Contents101
- Reset Menu101
Troubleshooting102
Using the Help103
Problem Solving104
- Reading the Indicators104
- When the Indicators Provide no Help108
- Problems Relating to Images109
- Problems When Projection Starts115
  - The Projector Does Not Turn on115
- Other Problems115
Maintenance118
Cleaning119
- Cleaning the Projector's Surface119
- Cleaning the Lens119
- Cleaning the Air Filter119
Replacing Consumables121
- Replacing the Lamp121
- Replacing the Air Filter124
  - Air Filter Replacement Period124
  - How to Replace the Air Filter124
Appendix126
Optional Accessories and Consumables127
- Optional Accessories127
- Consumables127
Screen Size and Projection Distance128
- Projection Distance (for EB-X25)128
- Projection Distance (for EB-X22/EB-X21/EB-X20/EB-X17)129
- Projection Distance (for EB-W22)130
- Projection Distance (for EB-S21/EB-S17)131
Supported Monitor Displays133
- Supported Resolutions133
Specifications135
- Projector General Specifications135
Contents139
Appearance139
Glossary140
General Notes142
- About Notations142
- General Notice143
Index144
