Cooling Mechanism Devices
“ 3.3.2 Lamp (p55)”
“ 3.3.5 Removing the Upper Case
(assembly) (p59)”
“ 3.3.8 Removing the MA Board
(assembly) (p68)”
“ 3.3.8.3 DR Board (EH-TW4500/
5500 series only) (p73)”
“ 3.3.4 Side Case L/Side Case R
(p57)”
Start
“ 3.3.11.1 INT Fan (p87)”
“ 3.3.7 Removing the EX Fan
(assembly) (p65)”
“ 3.3.7.1 EX Fan (p66)”
“ 3.3.11 INT Fan (assembly) (p85)”
“ 3.1.6 Precautions for Optical
Engine and MA Board (p50)”
“ 3.3.7.2 PS Fan (p67)”
“ 3.3.10 Lamp Fan (p83)”
