Table 3-6. Components of Optical Engine and MAB set
Part name Qt. Part name (SPI)
Optical Engine 1 OPTICAL ENGINE
CF Motor 1 MOTOR CF ASSY.
Auto Iris 1 AUTO IRIS ASSY
GND cable (1) 1 CABLE,GND
GND cable (2) 1 CABLE, GND
CF Frame 1 FRAME CF ASSY.
ML Fasten Spring 1 SPRING,ML FASTEN,TOP
CF Switch 1 SW CF ASSY.
CF Plate 1 PLATE,CONDUCTION,CF
LG Spring 1 SPRING,LG FASTEN
Focus Ring 1 FOCUS RING;S
Zoom Ring 1 ZOOM RING
Left MA Plate 1 PLATE,MAFASTEN;LEFT
Right MA Plate 1 PLATE,MAFASTEN;RIGHT
DR Board (assembly) 1
PRINTED CIRCUIT BOARD
ASSEMBLY;DR_R1
Gasket (3) 3 GASKET 2_3_35
Gasket (2) 1 GASKET 13_10_40
EMI Sheet 4 EMI, SUPPRESOR
