Epson EH-TW7000 User Manual

Basic Operations
26
If the target image is not projected
If the image is not projected, you can change the source using one of the following methods.
Remote control Control panel
Press the button for the target port. Press the [Home] button, and then select the target in-
put source on the home screen displayed.
Using the Home Screen
The Home screen feature allows you to easily select an image source and access useful functions.
Press the [Home] button on the remote control or the control panel to display the Home screen.
Under the following conditions, the Home screen is displayed automatically when the projector is turned on.
•
Home Screen Auto Disp. is set to On. s Extended - Home Screen - Home Screen Auto Disp. p.65
•
There are no signals from any sources.
a
Selects the source you want to project.
b
Displays the Connection Guide.
c
Displays the Configuration menu. s p.58
d
Performs menu options assigned to Custom Function 1 and Custom Function 2 on the Home Screen.
s Extended - Home Screen p.65
e
Sets the 3D function. s Signal - 3D Setup p.61

Epson EH-TW7000 Specifications

General

Matrix size	0.61 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	2.95 - 4.77 m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	40000:1
Screen size compatibility	40 - 500 \
Projector native resolution	2160p (3840x2160)
Keystone correction, horizontal	-30 - 30 °
Noise level	32 dB
Country of origin	Philippines
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	24 dB
Built-in speaker(s)	No
Lamp type	UHE
Lamp power	250 W
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Focus	Manual
Throw ratio	1.32 - 2.15:1
Zoom capability	Yes
Focal length range	18.2 - 29.2 mm
Aperture range (F-F)	1.49 - 1.77
Vertical lens shift range	-60 - 60 %
Horizontal lens shift range	-24 - 24 %
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Video processing	10 bit
Video color modes	Auto, Cinema, Dynamic, Natural, Bright cinema
Supported 3D formats	Side by side, Top and bottom
Supported video modes	2160p
Supported 3D technologies	Samsung Active 3D
Analog signal format system	-
Supported graphics resolutions	3840 x 2160
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	368 W
Power consumption (PowerSave)	280 W
Serial interface type	RS-232C
USB 2.0 ports quantity	2
VGA (D-Sub) ports quantity	0
Mini-USB 2.0 ports quantity	1
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 30 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	18 pc(s)
Quantity per pallet (UK)	36 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	85286200
Quantity per pallet layer (UK)	4 pc(s)

Weight and Dimensions

Depth	310 mm
Width	410 mm
Height	157 mm
Weight	6600 g
Package depth	495 mm
Package height	230 mm
Package weight	8710 g
