Epson EH-TW9400 User Manual

Contents
4
Adjust using the gamma adjustment graph
.................................. 40
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 42
Saving a Memory ....................... 42
Loading, Deleting, and Renaming a Memory
.................................... 42
Useful Functions
Enjoying 3D Images .................. 44
Preparing to View 3D Images ..............44
If the 3D image cannot be viewed ......... 44
Using 3D Glasses ....................... 45
Warnings Regarding Viewing 3D Images......45
Connecting with WirelessHD
. . . . . . . . 47
Installing the WirelessHD Transmitter........47
WirelessHD Transmitter part names ........ 48
WirelessHD Transmitter connection
example and signal flow ................ 49
Setting the WirelessHD Transmitter ........ 54
Projecting Images ...................... 54
WirelessHD Settings Menu ................56
WirelessHD Transmission Range ............57
Operating the Remote Control............. 58
Remote Control Operating Range ........... 58
Switching the Input and Output............ 58
Switching the target image .............. 59
Switching the image source .............60
Using the HDMI Link Function ........ 61
HDMI Link Function ..................... 61
HDMI Link Settings ...................... 61
Connecting ........................... 62
Using the Projector on a Network
Projecting Using Wired LAN .......... 63
Selecting Wired Network Settings ...........63
Projecting Using Wireless LAN ........ 65
Selecting Wireless Network Settings Manually
.................................... 65
Selecting the Computer's Wireless LAN Settings
....................................67
Selecting wireless network settings in
Windows ........................... 67
Selecting wireless network settings in OS X
.................................. 67
Setting Up Wireless Network Security . . . . . . . . 68
Projecting in Epson iProjection (iOS/Android)
....................................68
Operating using a smartphone (remote
control function) .....................69
Configuration Menu
Configuration Menu Functions ........ 71
Configuration Menu Operations............71
Configuration Menu Table ................72
Image menu ........................72
Signal menu........................ 74
Settings menu ....................... 75
Extended menu ...................... 78
Network menu ....................... 82
Info menu .......................... 86
Reset menu ......................... 86
Troubleshooting
Problem Solving . .................... 87
Reading the Indicators ................... 87
Indicator status during an error/warning....87
Indicator status during normal operation . . . . 89
When the Indicators Provide No Help........89
Check the problem .................... 89
Problems relating to images.............90
Problems when projection starts .......... 94
Problems with the remote control ......... 94
Problems with the control panel ..........94
Problems with 3D .................... 95
Problems with HDMI .................. 95
Problems with WirelessHD (EH-TW9400W/
EH-TW8400W only) ................... 96
Network problems .................... 98
About Event ID........................ 98

Epson EH-TW9400 Specifications

General

Matrix size	0.74 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	3 - 6.3 m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	1200000:1
Screen size compatibility	50 - 300 \
Projector native resolution	2160p (3840x2160)
Keystone correction, vertical	-30 - 30 °
Lamp type	UHE
Lamp power	250 W
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Full HD	Yes
Video processing	10 bit
Video color modes	Cinema, Dynamic, Natural, Bright cinema
Supported 3D formats	Side by side, Top and bottom
3D video colour modes	3D Dynamic, 3D Cinema
Analog signal format system	Not supported
Throw ratio	1.35 - 2.84:1
Focal length range	22.5 - 46.7 mm
Aperture range (F-F)	2 - 3
Vertical lens shift range	-96.3 - 96.3 %
Horizontal lens shift range	-47.1 - 47.1 %
DVI port	No
Audio (L/R) in	-
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	Black
Market positioning	Home cinema
Cable lock slot type	Kensington
Noise level	31 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Noise level (economic mode)	20 dB
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	355 W
Power consumption (economy mode)	271 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Cables included	AC, HDMI
Bundled software	EasyMP Multi PC Projection
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	16 pc(s)
Quantity per pallet layer	2 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Control4

Weight and Dimensions

Depth	450 mm
Width	520 mm
Height	193 mm
Weight	11200 g
Package depth	654 mm
Package width	512 mm
Package height	264 mm
Package weight	14420 g
