FX-870/1170
Bin capacity:
Single sheets:
Envelopes:
MCBF:
Paper:
C806371
and
C806391
Up to 50 sheets of 82-g/m’ (22-lb) paper
006381
and
C806401
Up to 150 sheets of 82-g/m* (22-lb) paper
006381
and
C806401
Up to 25 (plain and bond type)
Up to 30 (air mail)
100,000 cycles
Paper storage conditions:
Temperature:
18"
to
22"C(64"
to 72°F)
Humidity: 40% to 60% RH
Environmental Temperature:
Operation:
5"
to 35°C (41” to 95°F)
Storage:
-30" to 60°C
(-22” to
140°F)
Humidity (without condensation):
Operation:
15%toSO%
RH
Storage:
5%
to 85%
RH
Note:
Cl
24-lb paper printing
is
available only at normal operating
conditions.
Cl
Cut-sheet feeder envelope printing is available only with the
C806381 or C806401
cut-sheet
feeders
and only at normal
operating
conditions.
Front sheet guide
Dimensions and weight:
Printer Optlon Helght Width Depth Weight
No.
Standard
C814001
48.5 mm
332mnl 177mm
280 g
Wide
C814011
48.5 mm
507mm
177mm
450 g
Paper:
Single sheets
1
Multi-psrt forms
Width
C814001
148 to 257 mm
(5.8 to 10.1 inches)
C814011
14810364mm
(5.8 lo 14.3 inches)
Paper length
max. 364 mm
(max. 14.3
Inches)
Thickness
0.085 to 0.14 mm
0.12
too.32
mm
(0.0025 to 0.0054 in.)
(0.0047 to 0.0125 in.)
Weight
64toQOg/m2
(40 to 58 g/m’)
x
4
(14 to 24 lb)
[(12
to 15 lb)]
x
4
Printable area:
Single sheets:
Same as single sheets from the top insertion.
(Multi-part forms)
Note:
Front sheet guiak is available
only
at the normal operating
conditions.
Character Tables
ESUP
mode
This section lists the character tables available in the
ESC/P
mode.
You can select these character tables with the default-setting
mode or by using a software command.
All tables except the italic character table are the same as
PC437 table for hex codes 00 through
7F,
so only the PC437
and italic tables are shown completely. The rest of the tables
show only the characters for hex code-s 80 through FF.
PC437
(USA,
Standard Europe)
FX-870/1170-4 10/13/92
