FX-870/1170
Auto carriage return
When the auto carriage return is valid, each line feed (LF)
code or ESC J (n/216-inch line feed) code is always
accompanied by a carriage return (CR) code. The printer
always moves the next print position to the left margin when
it receives the LF or ESC J code. When this feature is invalid,
you must send the CR code after the line feed code to move
the print position to the left margin. This feature is available
in IBM emulation mode only.
Changing Group 1 default settings
1. Make sure the printer is turned off,
2. Turn on the printer while you hold down the FONT button.
This enters the Group 1 default setting mode. The printer
beeps several times.
3. Load single-sheet or continuous paper. The printer then
automatically loads the paper and prints a quick reference.
Group 1 default settings
FONT COND. Feature
light
Settings READY
light
ON BLINK Skip-over-
perforation
BLINK OFF
Shape of Zero
BLINK ON Tear off
BLINK BLINK Auto line feed
(A4)
BLINK
No skip OFF
Skip 1 inch ON
0 OFF
0 (with slash) ON
Valid OFF
Invalid ON
Deoends on
OFF
in&ace
Valid
ION
The FONT and CONDENSED lights show which feature you
have button as many times as necessary until the FONT
and CONDENSED lights match your selection.
For example, if you want to change the character spacing,
press the FONT button until the FONT light is off and the
CONDENSEDlight is blinking.
Next, press the PAUSE button to change the setting. The
READY light shows your selection.
For example, if you want to change to 12 cpi, press the
PAUSE button once to turn the READY light on.
If necessary, repeat this process for any other Group 1
features you want to change.
Exit the Group 1 default-setting mode at any time by
turning off the printer. Any changes you have made
remain in effect until you change them again.
Note: If you want to check the new default settings, enter the
a!+ulf-setting mock again and print the quick re$rence. After that,
turn oftke printer to exit the default-setting mode.
Changing Group 2 default settings
1. Make sure the printer is turned off.
2. Turn on the printer while you hold down the FONT and
PAUSE buttons. This enters the Group 2 default-setting
mode. The printer beeps several times.
3. Load single-sheet or continuous paper. The printer then
automatically loads the paper and prints a quick reference
according to the emulation setting in Group 1.
ESUP mode character table
1 FONT 1 COND. 1 READY 1 ESUP mode Character tables
IBM mode character table
1 FONT 1 COND. 1 READY 1 IBM mode Character tables
Press the FONT button to select the character table. The
FONT, CONDENSED and READY lights turn on, off, or blink
to show your selection.
For example, if you select PC437 (USA, standard Europe),
the FONT light is on, the CONDENSED light is off, and the
READY light is off.
After you have made your selection, exit the Group 2
default-setting mode by turning off the printer.
Note: .?f you want to check the new default settings, enter the
defaulf-setting mode again and print the quick reference. After that,
turn ofthe printer to exit the default-setting mode.
FX-870/1170-8 10/13/98
9-Pin Printers

Epson FX-1170 Specifications

General

Print Method	Impact dot matrix
Connectivity	Parallel interface
Number of Pins	9
Paper Handling	Tractor feed
Print Width	136 columns (at 10 cpi)
Paper Path	Front, Rear
Paper Size	Continuous paper
Noise Level	55 dB
