Disassembly/Reassembly Overview 22
L120 Revision A
CR Unit 9:55 --- 9:55
CR Timing Belt
6:28 --- 6:28
CR Encoder Sensor 6:30 --- 6:30
Frame Base Assy 10:21 --- 10:21
Pump Unit
12:23 --- 12:23
Spur Gear 16.5 12:47 --- 12:47
PF Roller Unit
15:08 5:51 20:59
PF Motor Assy
15:55 1:08 17:03
Frame Base 15:55 --- 15:55
Tube Guide Sheet Sub
2:26 --- 2:26
Joint
4:16 --- 4:16
Tube Pressing Plate
2:12 --- 2:12
Star Wheel Holder Assy
2:46 3:18 6:04
EJ Roller
3:21 3:18 6:39
Ink Supply Tube Assy
3:30 --- 3:30
Tube Guide Sheet
2:58 --- 2:58
Adapter
2:43 --- 2:43
Holder Board
2:58 --- 2:58
Printhead
4:46 17:39 22:25
Cap Tank
0:57 --- 0:57
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total
