Disassembly/Reassembly Overview 30
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series Revision A
 It is recommended that the ink in the Ink Supply Tank should be discharged completely before
proceeding to disassembling/reassembling.
 After all the reassembling work is complete, the discharged ink of each color should be refilled
back to the Ink Supply Tank before performing the adjustment. Confirm the colors indicated on
the film of the Ink Supply Tank so as not to mistake them, and make sure to refill each ink back to
the correct tank from the corresponding ink supply hole.
Ink supply hole
Ink Supply Tank Assy

Epson L130 Specifications

General

Print Technology	On-demand inkjet (Piezo electric)
Print Resolution	5760 x 1440 dpi
Connectivity	USB 2.0
Minimum Ink Droplet Size	3 pl
Output Tray Capacity	30 sheets
Ink Colors	Black, Cyan, Magenta, Yellow
Weight	2.7 kg
Print Speed	Black: 27 ppm, Color: 15 ppm
Paper Capacity	50 sheets
Ink Type	Dye Ink
Compatible Operating Systems	Windows XP/Vista/7/8/8.1/10, Mac OS X 10.6.8 or later
Paper Sizes	A4, A5, A6, B5, Letter
Ink Bottles	Cyan, Magenta, Yellow, Black
Print Method	On-demand inkjet (Piezoelectric)
