7.3 Warning code
Structure
Item Byte (Hex) Value (Hex)
Header 1 04
Parameter counter 1 Warning kinds
Parameter n Occurred all warning code
The parameter <warning code> is one-byte Binary and indicates the warning code as follows,
<warning code> is consisted of the several fields as shown below.
When several warning appears at the same time, reply all the warning codes with the format below.
value [value value ⋅⋅⋅⋅⋅⋅].
<warning code> field is recognized in the following warning state. (This field is not recognized in @BDC-ST character string
when no warning is received)
For ink low warning, the order depends on the ink cartridge order.
The parameter is as follows.
Warning
Warning code
Ink low (Black[Pigment])
10
Ink low (Cyan)
11
Ink low (Yellow)
12
Ink low (Magenta)
13
Ink low (Black[Dye])
14
Cleaning disable (Black[Pigment])
51
Cleaning disable (Cyan)
52
Cleaning disable (Yellow)
53
Cleaning disable (Magenta)
54
Cleaning disable (Black[Dye])
55
