Control Panel
The indicator lights give you the current status of the printer. The buttons let you
control many printer settings.
Lights
OPERATE (green)
On when the operate switch is on and power is supplied.
PAUSE (orange)
On when the printer is not ready to print data. The
PAUSE
light is off unless you
press the pause button to prevent printing.
DATA (orange)
On when the printer's buffer contains data.
MULTI-PART (green)
On when you move the paper-thickness lever to position 2 or higher. The printing
speed is reduced when this light is on. When this light is flashing, vou can use the
micro-feed feature.
PAPER OUT (red)
On when the printer runs out of paper.
BIN 1 (green)
On when bin 1 of the optional cut-sheet feeder is selected for paper feeding.
BIN 2 (green)
On when bin 2 of the optional cut-sheet feeder is selected for paper feeding.
TEAR OFF (yellow)
On when you press the
TEAR OFF
button to feed continuous paper to the tear-off
position.
CONDENSED (green)
On when you select condensed printing from the control panel.
FONT (green)
On when a specific font is selected. When you select Roman T or Sans Serif H with
your software, all the
FONT
lights are turned off.
