Why is my Epson LQ-590II printing strange symbols?
If your Epson printer prints strange symbols, incorrect fonts, or other inappropriate characters, it means that your printer and computer are not communicating correctly. Make sure that you use the correct interface cable and that the communications protocol is correct.
What to do if Epson Printer printout is pale?
If your Epson printer's printout is pale, it could be due to the printing speed being set to Ultra high speed draft (USD). Change the printing speed setting. Another potential cause is a worn-out ribbon. Replace the ribbon cartridge.
What to do if Epson LQ-590II Printer printout is faint?
If your Epson printer's printout is faint, it might be because the paper-thickness lever is set incorrectly for your paper. Move the paper-thickness lever to a lower setting. Also, the ribbon could be worn out; in this case, replace the ribbon cartridge.
Why Epson Printer does not print when using a network?
If your Epson printer doesn't print when using a network, the network setting might be wrong. Check if print jobs from other computers are being printed through the network. If not, network settings may be incorrect. Ask your network administrator for help.
Why is the printout faint on my Epson LQ-590II Printer?
If the printout from your Epson printer is faint, the paper-thickness lever might be set incorrectly for your paper. Move the paper-thickness lever to a lower setting.
What to do if continuous paper is not fed to the standby position in Epson Printer?
Tear off the printed page at the perforation. Then press the Load/Eject button on your Epson printer. The printer feeds the paper to the standby position.
What to do if the print head is overheated in Epson Printer?
Wait for a few minutes; the Epson printer resumes printing automatically once the print head cools.
What to do if Epson Printer printout has extra blank lines between lines of text?
If your Epson printer's output has extra blank lines, it's likely because two line feed commands are being sent. This happens when the printer’s auto line feed setting is on. Turn off the auto line feed setting using the printer’s Default Setting mode.
What to do if Epson LQ-590II has lines of dots missing in the printout?
If you notice lines of dots missing in your Epson printer's output, it indicates that the print head is damaged. Stop printing and contact your dealer to have the print head replaced.
What to do if Epson Printer prints all the text on the same line?
If your Epson printer prints all text on one line, it means no line feed command is being sent. Turn on the auto line feed setting using the printer’s Default Setting mode so that the printer automatically adds a line feed code to each carriage return.
General| Mean time between failures (MTBF) | 25000 h |
|---|---|
| Color | - |
| Character sets | ISO 8859-15, Italic, PC437, PC850, PC858, Roman 8 |
| Built-in barcodes | Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E |
| Maximum printing width (columns) | 80 |
| Standard interfaces | Ethernet, USB 2.0 |
| Continuous paper thickness range | 0.065 - 0.49 mm |
| Sustainability certificates | ENERGY STAR |
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 10 - 80 % |
| Product color | Black |
| Country of origin | Indonesia |
| Sound pressure level (printing) | 55 dB |
| Pallet width | 800 mm |
| Pallet height | 7430 mm |
| Pallet length | 1200 mm |
| Pallet width (UK) | 1000 mm |
| Quantity per pallet | 14 pc(s) |
| Quantity per pallet (UK) | 28 pc(s) |
| Quantity per pallet layer | 2 pc(s) |
| Quantity per pallet layer (UK) | 4 pc(s) |
| Package depth | 340 mm |
| Package width | 40 mm |
| Package height | 80 mm |
| Package weight | 9280 g |
| Quantity per pack | 1 pc(s) |
Weight and Dimensions| Depth | 375 mm |
|---|---|
| Width | 437 mm |
| Height | 177 mm |
| Weight | 7200 g |
Lists the manuals supplied with your Epson printer.
Explains conventions like screenshots and illustrations in the manual.
Lists the operating systems referred to in the manual.
Defines Warnings, Cautions, and Notes for user safety and equipment protection.
Explains the symbol indicating hot printer parts and advises caution.
Advises reading all safety instructions and following warnings on the printer.
Explains how to select paper sources for single sheets and continuous paper.
Details options for continuous paper printing using tractor positions and entry slots.
Explains how to align paper supply with the tractor for smooth feeding.
Provides instructions for loading paper based on tractor position.
Step-by-step guide to install the tractor in the front push position.
Step-by-step guide to install the tractor in the pull position.
Explains manual and automatic methods for removing continuous paper.
Provides steps to remove continuous paper using the Tear Off/Bin button.
Lists paper types and their corresponding available paper slots.
Explains how to install and use the front sheet guide for paper loading.
Details printing on single-sheet and continuous multipart forms.
Introduces Epson software, including printer driver and Status Monitor 3.
Explains how to access and use the printer driver from Windows applications or Start menu.
Accesses EPSON Status Monitor 3 to monitor printer status and errors.
Opens dialog to configure EPSON Status Monitor 3 settings.
Utility for adjusting vertical line misalignment.
Opens utility dialog to change printer settings.
Instructions on how to change printer settings using the utility.
Describes how to share the printer on a standard Windows network.
Identifies and explains the printer's control panel buttons and lights.
Explains the default settings and options configurable via the control panel.
Details how to turn lock-out mode on, off, or change locked functions.
Explains how to diagnose printer problems using control panel lights and beep patterns.
Provides Epson support website addresses for help and downloads.
Advises on information needed when contacting customer support.
Guides on what information to provide for faster customer support.
Explains how to replace the ribbon cartridge, with warnings about hot parts.
Lists part numbers for single-bin cut-sheet feeders.
Provides steps to install single-bin, high-capacity, or double-bin cut-sheet feeders.
Step-by-step instructions to assemble the roll paper holder.
Steps to load a roll of paper after installing the roll paper holder.
Identifies and labels the various parts of the printer.
Details mechanical specifications like printing method, speed, and resolution.
Lists the available printer interfaces (Parallel, USB, Serial, Network).
Specifies the printer's buffer size.
Lists the bitmap and scalable fonts supported by the printer.
Specifies rated and input voltage/frequency ranges for the printer.
Specifies the rated current consumption for the printer.
Details paper specifications for single sheets (width, length, thickness, weight).
Details paper specifications for single-sheet multipart forms (width, length).
Lists Epson ESC/P control codes for general operation and paper feeding.
Lists safety and EMC approvals for US and Canadian users.
Mentions CE marking and compliance with EU Directives.
