2 parallel interface connector Connects the parallel interface cable.
3 serial interface connector Connects the serial interface cable.
4 AC inlet Connects the power cable.
1 upper mechanism The unit that prints on paper.
2 release lever Releases the upper mechanism to make it easier to remove paper
when the paper is jammed.
3 print head Prints on paper.
4 ribbon cartridge Contains ink ribbon.
5 ribbon-tightening knob Turn this to remove any slack in the ribbon.
PLQ-35 User’s Guide
Printer Basics 16
