Epson PowerLite S7 User Manual

Presenting With the Remote Control 51
To control presentation slides using the remote control’s Page Up or
Page Down buttons, select Page Up/Down as the USB Type B
setting on the Extended menu (see page 60). Then you can control
your presentation using those buttons.
If you want to use the remote control as a wireless mouse, select
Wireless Mouse as the USB Type B setting on the Extended menu
(see page 60). Then you can control your presentation as follows:
■ Use the arrow buttons to move the cursor on the screen.
■ Press the Enter button once to left-click, or twice to double-click.
Press the
Esc button to right-click.
■ To drag-and-drop, hold down the Enter button. Then use the
arrow buttons to drag the object. When it’s where you want it,
release the
Enter button.
Page up or down
to change slides
in PowerPoint
Right-click
Left-click

Epson PowerLite S7 Specifications

General

projection system	Epson 3LCD, 3-chip optical engine
pixel number	480, 000 dots (800 x 600) x 3
native resolution	800 x 600 (SVGA)
resize	640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (SXGA1), 1280 x 800 (WXGA), 1440 x 900 (WSXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2), 1400 x 1050 (SXGA+)
throw ratio range	1.45 – 1.96 (4:3)
size (projected distance)	30" – 350" (2.9' – 34.4')
keystone correction manual vertical	± 30 degrees
white light output	2300 lumens (ISO 21118 Standard)
color light output	2300 lumens
lamp type	175 W UHE (E-TORL)
lamp life (ECO mode)	up to 5000 hours
lamp life (normal mode)	up to 4000 hours
power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	244 W (Normal Mode), 2.6 W Standby (Communication On), 0.3 W Standby (Communication Off)
operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
speaker	1 W (Mono)
fan noise (normal mode)	34 dB
fan noise (ECO mode)	29 dB

Weight and Dimensions

dimensions (W x D x H) including feet	11.6" x 9.0" x 3.1"
dimensions (W x D x H) excluding feet	11.6" x 9.0" x 3.0"
weight	5.1 lb/2.3 kg
