Epson PowerLite S7 User Manual

Maintaining the Projector 71
You can remove the air filter to clean both sides
If the filter is too dirty or broken, replace the filter as described below.
Replacing the Air Filter
You need to replace the air filter if:
■ You cannot remove the dust from it
■ The air filter is damaged or torn
■ You repeatedly see a projected message telling you to clean or
replace it
Contact your dealer or call Epson at 800-GO-EPSON
(800-463-7766) to obtain a new air filter. Request part number
V13H134A25.
1. Turn off the projector and unplug the power cord.
2. Open the air filter cover on the side of the projector.
3. Lift the air filter out of its slot as shown.
note
Air filters contain
polycarbonate, ABS resin,
and polyurethane foam.
Dispose of used air filters
according to local
regulations.

Epson PowerLite S7 Specifications

General

projection system	Epson 3LCD, 3-chip optical engine
pixel number	480, 000 dots (800 x 600) x 3
native resolution	800 x 600 (SVGA)
resize	640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (SXGA1), 1280 x 800 (WXGA), 1440 x 900 (WSXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2), 1400 x 1050 (SXGA+)
throw ratio range	1.45 – 1.96 (4:3)
size (projected distance)	30" – 350" (2.9' – 34.4')
keystone correction manual vertical	± 30 degrees
white light output	2300 lumens (ISO 21118 Standard)
color light output	2300 lumens
lamp type	175 W UHE (E-TORL)
lamp life (ECO mode)	up to 5000 hours
lamp life (normal mode)	up to 4000 hours
power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	244 W (Normal Mode), 2.6 W Standby (Communication On), 0.3 W Standby (Communication Off)
operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
speaker	1 W (Mono)
fan noise (normal mode)	34 dB
fan noise (ECO mode)	29 dB

Weight and Dimensions

dimensions (W x D x H) including feet	11.6" x 9.0" x 3.1"
dimensions (W x D x H) excluding feet	11.6" x 9.0" x 3.0"
weight	5.1 lb/2.3 kg
