Epson PowerLite S7 User Manual

56 Fine-Tuning the Projector
2. Adjust the desired options as needed:
■ Color Mode
Lets you quickly adjust the color and brightness for various
environments. You can save a different setting for each
source. See page 44 for a description of each color mode.
■ Brightness
Lightens or darkens the overall image.
■ Contrast
Adjusts the difference between light and dark areas.
■ Color Saturation
Adjusts the color depth of the image.
■ Tint
Adjusts the balance of green to magenta in the image.
■ Sharpness
Adjusts the sharpness of the image.
■ Color Temp.
Sets the color temperature of the image. Select High to tint
the image bluer or
Low to tint it redder (default setting is
Medium). (Not available if sRGB is selected as the Color
Mode setting.)
■ Color Adjustment
Adjusts the color values. Select Red, Green, Blue to adjust
red, green, and blue hue and saturation values. (Not available
if
sRGB is selected as the Color Mode setting.)
■ Auto Iris
Automatically adjusts the projected luminance according to
the brightness of the image. (Available only when
Dynamic
or Theater is selected as the Color Mode for the current
input source.)
note
The available settings vary
depending on the input
source selected.
The
Brightness setting
changes the opacity of the
projector’s LCD panels. You
can also change the lamp’s
brightness. Select
Power
Consumption
in the
Settings menu, then choose
Normal or ECO (the
default setting is Normal).

Epson PowerLite S7 Specifications

General

projection system	Epson 3LCD, 3-chip optical engine
pixel number	480, 000 dots (800 x 600) x 3
native resolution	800 x 600 (SVGA)
resize	640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (SXGA1), 1280 x 800 (WXGA), 1440 x 900 (WSXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2), 1400 x 1050 (SXGA+)
throw ratio range	1.45 – 1.96 (4:3)
size (projected distance)	30" – 350" (2.9' – 34.4')
keystone correction manual vertical	± 30 degrees
white light output	2300 lumens (ISO 21118 Standard)
color light output	2300 lumens
lamp type	175 W UHE (E-TORL)
lamp life (ECO mode)	up to 5000 hours
lamp life (normal mode)	up to 4000 hours
power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	244 W (Normal Mode), 2.6 W Standby (Communication On), 0.3 W Standby (Communication Off)
operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
speaker	1 W (Mono)
fan noise (normal mode)	34 dB
fan noise (ECO mode)	29 dB

Weight and Dimensions

dimensions (W x D x H) including feet	11.6" x 9.0" x 3.1"
dimensions (W x D x H) excluding feet	11.6" x 9.0" x 3.0"
weight	5.1 lb/2.3 kg
