Maintaining the Projector 73
Contact your dealer or call Epson at 800-GO-EPSON
(800-463-7766). Request part number V13H010L54.
Follow these steps to replace the lamp:
1. Turn off the projector and unplug the power cord.
2. Let the projector cool for at least an hour (if it has been on). The
lamp is extremely hot immediately after use.
3. Loosen the lamp cover screw (you cannot remove it). Then slide
the lamp cover off.
4. Loosen the two screws holding the lamp in place (you can’t
remove them).
warning
Let the lamp cool fully
before replacing it.
In the unlikely event that
the lamp has broken, small
glass fragments may be
present and should be
removed carefully to avoid
injury. If the projector has
been installed on the ceiling,
you should stand to the side
of the lamp cover, not
underneath it.
If the lamp is used after the
replacement period has
passed, the possibility that
the lamp may break
increases. When a lamp
replacement message
appears, replace the lamp
with a new one as soon as
possible, even if it is still
working.
Loosen, but don’t
remove these screws

Table of Contents

Other manuals for Epson PowerLite S7

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson PowerLite S7 and is the answer not in the manual?

Epson PowerLite S7 Specifications

General IconGeneral
projection systemEpson 3LCD, 3-chip optical engine
pixel number480, 000 dots (800 x 600) x 3
native resolution800 x 600 (SVGA)
resize640 x 480 (VGA), 1024 x 768 (XGA), 1152 x 864 (SXGA1), 1280 x 800 (WXGA), 1440 x 900 (WSXGA), 1280 x 960 (SXGA2), 1280 x 1024 (SXGA3), 1280 x 768 (WXGA60-1), 1360 x 768 (WXGA60-2), 1400 x 1050 (SXGA+)
throw ratio range1.45 – 1.96 (4:3)
size (projected distance)30" – 350" (2.9' – 34.4')
keystone correction manual vertical± 30 degrees
white light output2300 lumens (ISO 21118 Standard)
color light output2300 lumens
lamp type175 W UHE (E-TORL)
lamp life (ECO mode)up to 5000 hours
lamp life (normal mode)up to 4000 hours
power supply voltage100 – 240 V ±10%, 50/60 Hz
power consumption244 W (Normal Mode), 2.6 W Standby (Communication On), 0.3 W Standby (Communication Off)
operating temperature41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
speaker1 W (Mono)
fan noise (normal mode)34 dB
fan noise (ECO mode)29 dB
Weight and Dimensions IconWeight and Dimensions
dimensions (W x D x H) including feet11.6" x 9.0" x 3.1"
dimensions (W x D x H) excluding feet11.6" x 9.0" x 3.0"
weight5.1 lb/2.3 kg
