G Scrap paper box
Holds waste paper that is cut
off during printing. Empty the scrap paper box when you replace the paper. Needs to
be removed when loading or removing paper.
See “Emptying the Scrap Paper Box” on page 61
H Print tray (optional)/Large print tray (optional)
Holds the ejected print outs.
See “Attaching and Removing the Print Tray (Optional)” on page 44
See “Attaching and Removing the Large Print Tray (Optional)” on page 46
I Cartridge cover (right)
Open when replacing ink cartridges or the maintenance tank.
See “Replacing Ink Cartridges” on page 48
See “Replacing the Maintenance Tank” on page 56
J Ink cartridges
K Roll paper feeder
Pull this to the front when removing the roll paper spindle.
Before Use
7
