Epson Stylus CX5600 - Button Functions in Stand-Alone Copy; Errors and Panel Status

EPSON Stylus CX4300/CX4400/CX5500/CX5600/DX4400/DX4450 Revision A
PRODUCT DESCRIPTION Specifications 21
1.2.11 Button Functions in Stand-alone Copy
The functions of the buttons in stand-alone copy mode are described in the table below.
1.2.12 Errors and Panel Status
Note * : When two or more errors occur at the same time, the one with higher priority will be
indicated.
Table 1-24. Buttons
Button Function
Power Turns the power on or off.
Stop
• Job cancel
Cancels a print or copy job, and ejects paper if paper has been fed inside.
• Head cleaning
Runs a head cleaning cycle when pressed for three seconds or longer. If
there is not enough ink for the cleaning, the cleaning is automatically
cancelled and the printer indicates Ink out error.
• Ink Cartridge replacement
Moves the carriage to the position for replacing an ink cartridge(s) when
pressed during Ink out error or No ink cartridge error.
Starts ink charging when pressed after replacing the ink cartridge(s).
Color Photo
• Photo copy
Makes a color copy on 4x6 or L-sized Photo Paper.
• Recovery from an error state
Executes the remaining job when pressed after the error cause is removed.
B&W Text
• B&W copy (100% scale with 3 mm margins)
Makes a B&W copy on A4 or Letter-sized Plain Paper.
• B&W copy (Fit to page)
When pressed for three seconds or longer, makes a B&W copy on A4 or
Letter-sized Plain Paper enlarging or reducing the original image to fit it to
the paper size.
• Recovery from an error state
Executes the remaining job when pressed after the error cause is removed.
Color Text
• Color copy (100% scale with 3 mm margins)
Makes a color copy on A4 or Letter-sized Plain Paper.
• Color copy (Fit to page)
When pressed for three seconds or longer, makes a color copy on A4 or
Letter-sized Plain Paper enlarging or reducing the original image to fit it to
the paper size.
• Recovery from an error state
Executes the remaining job when pressed after the error cause is removed.
B&W Text +
Stop
Makes a B&W copy on A4 or Letter-sized Plain Paper in Fast Economy print
mode. (100% scale with 3 mm margins)
Color Text +
Stop
Makes a color copy on A4 or Letter-sized Plain Paper in Fast Economy print
mode. (100% scale with 3 mm margins)
B&W Text +
Power
(Only for Latin models)
Selects Letter size for B&W and Color copy.
Color Text +
Power
(Only for Latin models)
Selects A4 size for B&W and Color copy.
Table 1-25. Errors and Panel Status
Error LED status Cause Recovery Priority
Fatal error
All LEDs
flash
Mechanical trouble
Turn the power Off. Remove
the cause and turn the power
back on. If the error still
occurs, call service.
1
Maintenance
request
All LEDs
lights
Some internal part
needs to be replaced
Call service.
2
Paper jam
Paper LED
flashes
A paper jam has
occurred
Remove the paper and press
B&W or Color Text button to
continue, or press Stop button
to cancel the job.
3
Paper out
Paper LED
lights
Failed to load the paper.
Load paper on the ASF
correctly, and press B&W or
Color Text button to continue,
or press Stop button to cancel
the job.
3
Ink out
Ink LED
lights
Some cartridge has run
out of ink.
Replace the cartridge with
EPSON genuine one.
4
No Ink
Cartridge
Ink LED
lights
Some cartridge was not
detected.
Replace the cartridge with
EPSON genuine one.
4
Incorrect Ink
Cartridge
Ink LED
lights
An incorrect cartridge
was detected.
Replace the cartridge with
EPSON genuine one.
4
